Product Class: Restriction Endonuclease

NheI
neb21 cloned at NEB recombinant time saver dil_C 37 65 Heat CpG

This product has been discontinued and is replaced with the High-Fidelity version, NheI-HF (NEB #R3131)

  • Catalog # R0131 was discontinued on March 17, 2021
NEB restriction endonuclease that recognizes the sequence G^CTAG_C

Product Introduction

Bioz Badge Exists : True

Product Information

Description

NheI has a High Fidelity version NheI-HF® (NEB #R3131).

High Fidelity (HF) Restriction Enzymes have 100% activity in CutSmart Buffer; single-buffer simplicity means more straightforward and streamlined sample processing. HF enzymes also exhibit dramatically reduced star activity. HF enzymes are all Time-Saver qualified and can therefore cut substrate DNA in 5-15 minutes with the flexibility to digest overnight without degradation to DNA. Engineered with performance in mind, HF restriction enzymes are fully active under a broader range of conditions, minimizing off-target products, while offering flexibility in experimental design.

Product Source

An E. coli strain that carries the NheI gene from Neisseria mucosa heidelbergensis (ATCC 25999).
This product is related to the following categories:

Properties & Usage

Unit Definition

One unit is defined as the amount of enzyme required to digest 1 µg of λ DNA (HindIII digest) in 1 hour at 37°C in a total reaction volume of 50 µl.

Reaction Conditions

1X NEBuffer™ 2.1
Incubate at 37°C

1X NEBuffer™ 2.1
50 mM NaCl
10 mM Tris-HCl
10 mM MgCl2
100 µg/ml BSA
(pH 7.9 @ 25°C)

Activity in NEBuffers

NEBuffer™ 1.1: 100%
NEBuffer™ 2.1: 100%
NEBuffer™ 3.1: 10%

Diluent Compatibility

Storage Buffer

10 mM Tris-HCl
250 mM NaCl
1 mM DTT
0.1 mM EDTA
200 µg/ml BSA
50% Glycerol
0.15% Triton® X-100
pH 7.4 @ 25°C

Heat Inactivation

65°C for 20 minutes

Methylation Sensitivity

dam methylation: Not Sensitive
dcm methylation: Not Sensitive
CpG Methylation: Blocked by Some Combinations of Overlapping

Product Notes

  1. Cleaves to leave a 5´ CTAG extension which can be efficiently ligated to DNA fragments generated by AvrII, SpeI or XbaI.
  2. Inhibited by salt concentrations > 100 mM.
  3. This enzyme has shown to have lower activity on some supercoiled plasmids, with more than 1 unit required to digest 1 μg plasmid DNA. For complete digestion of 1 μg of plasmid DNA please follow our recommended digestion protocol.
  4. Blocked by some combinations of overlapping CpG methylation.

Protocols, Manuals & Usage

Protocols

  1. Optimizing Restriction Endonuclease Reactions
  2. Restriction Digest Protocol
  3. Double Digest Protocol with Standard Restriction Enzymes

Usage & Guidelines

Tools & Resources

Selection Charts

Web Tools

FAQs & Troubleshooting

FAQs

  1. Is NheI affected by methylation?
  2. Are more units of NheI required to cut supercoiled DNA than lambda DNA?
  3. Is NheI inhibited by salt?
  4. Is NheI active at 25°C?
  5. Does NheI produce commonly used compatible ends?
  6. Do I have to set-up digests with Time-Saver™ qualified enzymes for 5-15 minutes? Can I digest longer?
  7. Which NEB restriction enzymes are supplied with Gel Loading Dye, Purple (6X)?

Troubleshooting
