Blue Prestained Protein Standard, Broad Range (11-250 kDa)

This product is a direct replacement of NEB# P7706 (Blue Prestained Protein Standard, Broad Range 11-190 kDa).

Product Introduction

The Blue Prestained Protein Standard, Broad Range is a mixture of highly pure, recombinant, prestained proteins, covalently coupled with a blue chromophore, that resolves into 11 sharp bands when electrophoresed.

  • Allows approximate molecular weight determination when performing SDS-PAGE analysis.
  • Applications include verification of Western transfer efficiency on membranes and fluorescent imaging of SDS-PAGE.
  • Direct loading, additional loading buffer and heat incubation not required
  • Recombinant proteins with no detectable protease contaminating activities
  • Optimal stability for up to 24 months



Blue Prestained Protein Standard, Broad Range (11-250 kDa)

Bioz Badge Exists : True
Catalog # Size Concentration
P7718S 0.45 ml 150 gel lanes
P7718L 2.25 ml 750 gel lanes

Product Information

Description

The Blue Prestained Protein Standard, Broad Range is a mixture of highly pure, recombinant, prestained proteins, covalently coupled with a blue chromophore, that resolves into 11 sharp bands when electrophoresed. The Blue Protein Standard is designed for observing protein separation during SDS-PAGE, verification of western transfer efficiency on membranes and for approximating the size of proteins (1-2). It may also be used in fluorescent imaging of SDS-PAGE.

Blue Prestained Protein Standard, Broad Range (11-250 kDa)

Blue Prestained Protein Standard, Broad Range (11–250 kDa) 10–20% Tris-glycine SDS-PAGE Gel




This product is related to the following categories:
Protein Standards,
Markers & Ladders,
Protein Standards,
This product can be used in the following applications:
Protein Standards,
Protein Analysis Tools

Reagents Supplied

Reagents Supplied

The following reagents are supplied with this product:

NEB # Component Name Component # Stored at (°C) Amount Concentration
  • NEB # Stored at (°C)
    P7718S -20
    Component Name Component # Stored at (°C) Amount Concentration
    Blue Prestained Protein Standard, Broad Range (11-250 kDa) P7718SVIAL -20 1 x 150 gel lanes Not Applicable
  • NEB # Stored at (°C)
    P7718L -20
    Component Name Component # Stored at (°C) Amount Concentration
    Blue Prestained Protein Standard, Broad Range (11-250 kDa) P7718SVIAL -20 5 x 150 gel lanes Not Applicable

Properties & Usage

Storage Buffer

62.5 mM Tris-phosphate
1 mM EDTA
2% SDS
10 mM DTT
1 mM NaN3
33% Glycerol
pH 7.5 @ -20°C

Features

  • Direct loading, additional loading buffer and heat incubation not required
  • Applications include verification of western blot transfer efficiency on membranes and fluorescent imaging of SDS-PAGE

Product Notes

  1. To ensure uniform mobility, load an equal volume of 1X Reducing SDS Loading Buffer into any unused wells.
  2. To maximize shelf life, store at -20°C. Guaranteed stable for 2 years when properly stored.
  3. It is not necessary to pre-heat the unstained protein standard prior to loading on a gel.
  4. Recommended mini-gel load: 3 μl.
  5. Apparent molecular weight values for prestained proteins can be different when run on different gel types and percentages.

References

  1. Laemmli, UK (1970). Nature. 227, 680.
  2. Sambrook, J., Fitsch, EF. and Maniatis, T. (2001). Molecular Cloning: A Laboratory Manual. (3rd ed.). Cold Spring Harbor: Cold Spring Harbor Laboratory Press.

FAQs & Troubleshooting

FAQs

  1. How does the new Blue Prestained Protein Standard, Broad Range differ from NEB’s previous Blue Prestained Protein Standard?
  2. What is the protein concentration of the proteins used in the Blue Prestained Protein Standard, Broad Range?
  3. What volume is supplied in a small pack and a large pack of NEB’s Protein Standards?
  4. I notice that the molecular weights I am observing are slightly different than those reported. Can you explain?
  5. I accidentally left my Protein Standard out at room temperature for a number of days. Is it still okay to use?
