Bst-XT WarmStart™ DNA Polymerase (Glycerol-free)

Need assistance designing LAMP primers? Use the NEB LAMP Primer Design Tool.



Product Introduction

  • Glycerol-free version of Bst-XT WarmStart™ DNA Polymerase (NEB #M9204) to support lyophilization and automation workflows
  • Combines the high specificity of Bst 2.0 and the polymerization speed of Bst 3.0 DNA Polymerases
  • Fused to novel nucleic acid binding domain for enhanced performance
  • Consistent amplification performance with the convenience of room temperature setup
  • WarmStart® technology eliminates off-target amplification and offers increased reaction efficiency
  • Offers fast polymerization rates and robust performance even in the presence of inhibitors, including dUTP
  • Broad optimal reaction performance from 50-70°C
  • View the Bst-XT: An improved Bst DNA polymerase to support loop mediated isothermal amplification NEB TV webinar
  • One of several products available glycerol-free
Bioz Badge Exists : True
Catalog # Size Concentration
M9205L 8000 units 120000 units/ml

Product Information

Description

Bst-XT WarmStart™ DNA Polymerase (Glycerol-free) is formulated without glycerol to support lyophilization, incorporation into microfluidic devices, and quick adoption into automation workflows.

Bst-XT WarmStart DNA Polymerase is an engineered variant of Bacillus stearothermophilus DNA Polymerase, Large Fragment fused to a novel nucleic acid binding domain for improved isothermal amplification performance. This enzyme combines the high specificity of Bst 2.0 and the fast polymerization speed of Bst 3.0 DNA polymerases.

  Bst-XT WarmStart
NEB #M9204		 Bst 2.0 WarmStart
NEB #M0538		 Bst 3.0
NEB #M0374
Icon for Bst polymerase product selection Amplification Speed ★★★★★ ★★★ ★★★★★
Icon for Bst polymerase product selection Specificity ★★★★★ ★★★★★ ★★
Icon for Bst polymerase product selection Room temp. set-up? Enabled Enabled Not recommended
Icon for Bst polymerase product selection Optimal LAMP temp 50-70°C 60-70°C 55-72°C
  Icon for Bst polymerase product selection Available glycerol-free Yes
NEB #M9205		 Yes
NEB #M0402		 Yes
NEB #M0443

Bst-XT WarmStart DNA Polymerase contains a reversibly bound aptamer, which inhibits polymerase activity at room temperature. The aptamer rapidly releases above 45°C, therefore no separate activation step is needed.

Bst-XT WarmStart DNA Polymerase contains 5´→3´ DNA polymerase activity with either DNA or RNA templates and strong strand displacement activity, but lacks 5´→3´ and 3´→5´ exonuclease activity.

Bst-XT WarmStart™ DNA Polymerase (Glycerol-free) has equivalent performance to glycerol-containing Bst-XT WarmStart DNA Polymerase

Plots of DNA and RNA targets showing same performance in glycerol-free format

LAMP (DNA targets, left panel) or RT-LAMP (RNA targets, right panel) experiments were performed with Bst-XT WarmStart DNA Polymerase (NEB #M9204) and Bst-XT WarmStart DNA Polymerase (Glycerol-free) (NEB #M9205) in Bst-XT isothermal amplification buffer. To detect RNA targets, WarmStart® RTx Reverse Transcriptase (NEB #M0380) was included in testing. Reactions containing 1X LAMP primers and 0.5X LAMP Fluorescent Dye (NEB #B1700) were set up in triplicate over three logs of total human Jurkat total RNA or Jurkat gDNA (10 ng to 0.1 ng) in 96-well, 25 µl reactions. Control reactions without template (NTC) were also evaluated. Reactions were incubated at 65°C for 30 minutes and fluorescence was monitored every 15 seconds in the SYBR/FAM channel of a real-time thermocycler (Bio-Rad® CFX96). Each dot represents the time at which the fluorescence signal for a single reaction crosses the instrument-defined threshold. All three replicates were detected at each template input unless otherwise indicated (note that dots frequently overlap given similar detection time for the replicates). Overall, similar performance was observed for both glycerol-containing and glycerol-free enzymes at each template input.
This product is related to the following categories:
Isothermal Amplification & Strand Displacement
This product can be used in the following applications:
Loop-Mediated Isothermal Amplification,
Isothermal Amplification

Reagents Supplied

Reagents Supplied

The following reagents are supplied with this product:

NEB # Component Name Component # Stored at (°C) Amount Concentration

Properties & Usage

Storage Buffer

20 mM Tris-HCl
100 mM KCl
0.5 mM TCEP
0.1 mM EDTA
1X stabilizers
pH 7.5

Tools & Resources

Web Tools

FAQs & Troubleshooting

FAQs

  1. Can Bst-XT DNA Polymerase be heat inactivated?
  2. Can Bst-XT DNA Polymerase be used at temperatures other than 65°C for LAMP reactions?
  3. Can Bst-XT DNA Polymerase be used in end point colorimetric detection?
  4. Can Bst-XT DNA Polymerase be diluted?
  5. How can I optimize LAMP/RT-LAMP reactions for difficult targets when using Bst-XT?
  6. How do I use Antarctic Thermolabile UDG for carryover prevention in LAMP reactions?
  7. How many Freeze/Thaw cycles can Bst-XT WarmStart® DNA Polymerase (Glycerol-free) tolerate?
  8. What are Hot Start and WarmStart® polymerases and when would I use them?
  9. What is LAMP and RT-LAMP?
  10. What is the recommended concentration of Mg+2 to use with Bst-XT in LAMP reactions?
  11. What is the difference between Bst DNA Polymerase, Large Fragment, Bst 2.0, Bst 3.0 and Bst-XT DNA Polymerase?
