Product Class: Kit

PURExpress® Δ Ribosome Kit

Additional PURExpress kit configurations are available for greater experimental flexibility and control. Explore your options.

Product Introduction

PURExpress® delta ribosome kit is a variation of the PURExpress In vitro Protein Synthesis Kit where ribosomes are omitted from the translation mix.

  • Control ribosomes provided separately
  • Designed for use with your own ribosomes
  • User supplied ribosomes can be E. coli-based wild type, mutant or ribosome from other bacterial species
  • Convenient for directly assaying ribosomal activity and translation studies
  • Defined system with all his-tagged proteins; Control Ribosomes provided are not his-tagged
  • Also available: PURExpress Δ (aa, tRNA) Kit (NEB #E6840), PURExpress Δ RF123 Kit (NEB #E6850), and PURExpress In Vitro Protein Synthesis Kit (NEB #E6800)
Bioz Badge Exists : True
Catalog # Size Concentration
E3313S 10 reactions

Product Information

Description

Highlights

  • Cleaner System - sample degradation eliminated
  • Easy-to-use - protein expression complete in approximately two hours
  • Simple Analysis - protein can often be visualized directly on a Coomassie stained gel
A rapid method for gene expression analysis, PURExpress® is a novel cell-free transcription/translation system reconstituted from the purified components necessary for E. coli translation. With minimal nuclease and protease activity, the PURExpress system preserves the integrity of DNA and RNA templates/complexes and results in proteins that are free of modification and degradation. Transcription and translation are carried out in a one-step reaction, and require the mixing of only two tubes. With results available in a few hours, PURExpress saves valuable laboratory time and is ideal for high throughput technologies.

PURExpress Citations


Figure 1: Protein expression using the PURExpress® In Vitro Protein Synthesis Kit

Gel depicting protein expression using the PURExpress® In Vitro Synthesis Kit

25 μl reactions containing 250 ng template DNA and 20 units RNase Inhibitor were incubated at 37°C for 2 hours. 2.5 μl of each reaction was analyzed by SDS-PAGE using a 10–20% Tris-glycine gel. The red dot indicates the protein of interest. Marker M is the Protein Ladder (NEB #P7703, discontinued and replaced with NEB #P7717).


Figure 2: Incorporation of 35S-methionine enables visualizationof protein by autoradiography

Gel depicting visualization of protein by autoradiography due to addition of 35S-methionine

25 μl reactions containing 250 ng template DNA, 20 units RNase Inhibitor and 2 μl 35S-met were incubated at 37°C for 2 hours. 2.5 μl of each reaction was analyzed by SDS-PAGE, the gel was fixed for 10 minutes, dried for 2 hours at 80°C and exposed to x-ray film for 5 hours at -80°C.


Figure 3: Schematic diagram of protein synthesis and purification by PURExpress

PURExpress® workflow for protein synthesis and purification


Figure 4: Expression and reverse purification of DHFR and T4 DNA Ligase using PURExpress

Gel depicting expression of DHFR and T4 DNA Ligase using PURExpress®

125 μl reactions were carried out according to recommendations in the accompanying manual. Samples were analyzed on a 10–20% Tris-glycine gel and stained with Coomassie Blue. Note that in both cases, the desired protein can be visualized in the total protein fraction. The red dot indicates the protein of interest. Marker M is the Protein Ladder (NEB #P7703, discontinued and replaced with NEB #P7717 ).


This product is related to the following categories:
PURExpress® In Vitro Protein Synthesis,
Total RNA Extraction & Purification,
Cell-Free Protein Expression,
Protein Expression,
This product can be used in the following applications:
PURExpress,
Cell-Free Protein Expression,
Protein Expression

Kit Components

Kit Components

The following reagents are supplied with this product:

NEB # Component Name Component # Stored at (°C) Amount Concentration
  • NEB # Stored at (°C)
    E3313S -80
    Component Name Component # Stored at (°C) Amount Concentration
    PURExpress Solution A B0228AVIAL -80 1 x 0.1 ml 2.5 X
    Factor Mix (30 μl) P0762AVIAL -80 1 x 0.03 ml Not Applicable
    E. coli Ribosome P0763AVIAL -80 1 x 0.01 ml 13.3 µM
    PURExpress Control DHFR Plasmid N0424AVIAL -20 1 x 0.01 ml 125 ng/µl

Properties & Usage

Materials Required but not Supplied

General: 37°C incubator

Labeling: 35S-Methionine (>1000 Ci/mmol recommended, in vitro translation grade)

TCA Precipitation: TCA solutions (25%, 10%), 1 M NaOH, casamino acids, ethanol, glass fiber filters, vacuum filtration manifold

SDS-PAGE: Gels and running buffer, gel apparatus, power supply, gel dryer

Western Blotting: Transfer apparatus, membrane, antibodies and detection reagent

Purification: Ni-NTA Agarose, Amicon Ultra- 0.5 ml, Ultracel- 100K Membrane Centrifugal Filters

Application Features

  • Quickly generate analytical amounts of protein for further characterization
  • Confirmation of open reading frames
  • Examination of the effects of mutations on ORFs
  • Generation of truncated proteins to identify active domains and functional residues
  • Introduction of modified, unnatural or labeled amino acids
  • Epitope mapping
  • Expression of toxic proteins
  • Ribosome display
  • Translation and/or protein folding studies
  • In vitro compartmentalization

Product Notes

  1. The DHFR control template is now supplied at 125 ng/µl. Use 2 µl for the positive control reaction. We use 60 pmoles of ribosomes in a standard 25 μl reaction. The supplied control ribosomes are enough for two reactions. Note: Using a smaller amount of ribosomes is possible but the protein yield may be lower.  For detailed usage information please refer to the product manual.
  2. PURExpress Control Template sequence files: Fasta, GenBank
  3. Storage: All kit components should be stored at -80°C.

References

  1. Gupta, P., K. Kannan, et al. (2013). Regulation of Gene Expression by Macrolide-Induced Ribosomal Frameshifting. Mol Cell. 52(5), 629-42. PubMedID: 24239289
  2. Tsai, A., J. Chen, et al. (2013). Observing Prokaryotic Translation Elongation in Real-Time using Single-Molecule Fluorescence. Biophysical Journal. 104(2, Supplement 1), 257a.
  3. Vazquez-Laslop, N., H. Ramu, et al. (2010). The key function of a conserved and modified rRNA residue in the ribosomal response to the nascent peptide. EMBO J. 29(18), 3108-3117. PubMedID: 20676057
  4. Vázquez-Laslop, N., H. Ramu, et al. (2011). Nascent peptide-mediated ribosome stalling promoted by antibiotics. Ribosomes. 377-392.
  5. Gupta, P., S. Sothiselvam, et al. (2013). Deregulation of translation due to post-transcriptional modification of rRNA explains why erm genes are inducible. Nat Commun . 4, 1984. PubMedID: 23749080
  6. Harvey, C. J., J. D. Puglisi, et al. (2012). Precursor directed biosynthesis of an orthogonally functional erythromycin analogue: selectivity in the ribosome macrolide binding pocket. J Am Chem Soc. 134(29), 12259-65. PubMedID: 22741553
  7. Kaiser, C. M., D. H. Goldman, et al. (2011). The ribosome modulates nascent protein folding. Science. 334(6063), 1723-7. PubMedID: 22194581
  8. Kannan, K., N. Vázquez-Laslop, et al. (2012). Selective Protein Synthesis by Ribosomes with a Drug-Obstructed Exit Tunnel. Cell. 151(3), 508-520. PubMedID: 23101624
  9. Kopaskie, K. S., K. G. Ligtenberg, et al. (2013). Translational regulation of Yersinia enterocolitica mRNA encoding a type III secretion substrate. Journal of Biological Chemistry. 288(49), 35478-88. PubMedID: 24158443
  10. Martínez, A. K., E. Gordon, et al. (2013). Interactions of the TnaC nascent peptide with rRNA in the exit tunnel enable the ribosome to respond to free tryptophan. Nucleic Acids Research. 42(2), 1245-56. PubMedID: 24137004
  11. Orelle, C., S. Carlson, et al. (2013). Tools for Characterizing Bacterial Protein Synthesis Inhibitors. Antimicrob Agents Chemother. 57(12), 5994-6004. PubMedID: 24041905
  12. Shi, W., X. Zhang, et al. (2011). Pyrazinamide inhibits trans-translation in Mycobacterium tuberculosis. Science. 333(6049), 1630-1632. PubMedID: 21835980

Tools & Resources

Selection Charts

FAQs & Troubleshooting

FAQs

  1. Where can I find many more detailed FAQs for PURExpress?
  2. How is the Δ Ribosome Kit E3313S different from the PURExpress E6800S kit?
  3. When using PURExpress, I was able to synthesize the target protein, but full-length product is not major species?
  4. When using PURExpress, I was unable to synthesize the control protein?
  5. When using PURExpress, I was able to synthesize the control protein, but the target sample is not present or present in low yield?
  6. Where can find all IMPACT FAQs?
  7. Are there PURExpress citations?

Tech Tips

Thaw and assemble reactions on ice
Thoroughly mix solutions A and B before using. Do not vortex Solution B or ribosomes, mix gently.
Solution A may have a cloudy white appearance. Add to the reaction as a uniform suspension.
Assemble the reactions in the following order on ice: Solution A, Solution B, RNAse Inhibitor, Water, Template DNA or RNA
Once reaction is assembled take time to make sure everything is thoroughly mixed by gently pipetting up and down, pulse spin and place at 37C for 2 to 4 hours.
